| Dimensions (LxWxH) | 16.930 mm x 2.800 mm x 4.015 mm |
| Weight | 36.250 kg |
| Engine type | CAT C 9.3 |
| Horsepower | 442 Hp |
| Bentonite pump capacity | 1892 ltr/min optional |
| Bentonite pump pressure | – |
| Rack and pinion | yes |
| Hydraulic anchoring system | – |
| Length Drillpipe | 9.60 mtr |
| Pipe diameter | 139 mm |
| OD tooljoint | 190 mm |
| Weight per pipe | 350 kg |
| Thrust-/pullback | 160.300 kg |
| Max spindle torque | 77.012 Nm |
| Max spindle speed | 66 rpm |
Of each type of machine sold, all parts and wear parts are sufficiently stocked. If parts are needed, they are brought directly via our own mobile service department or shipped via our logistics partners. NG Quality Drilling works with its own mechanics who communicate in the working language of the on-site personnel. The focus is on Germany, so the work area is of such a size that we can always be on site within 2 to 4 hours to repair faults.
The Apollo drilling machines, parts and wear parts are produced in India; a low-wage country. As a result, the costs for both the machine and the various parts are significantly lower, while, if we also consider that the Apollo has long been an established name within HDD in Asia, the quality is at least comparable to the providers, as we currently know them in Europe.
That math is easy to do:
The machine is manufactured in India. The low wages there result in a much lower cost of manufacturing the machine. In addition, there are no middlemen pushing the price up unnecessarily. Rhino Supply communicates and trades directly with the producing party in India. The lines are short, which also ensures that the cost of the machines is kept to a minimum.
The bottom line is that we ship the machine, which can be produced cheaply in India at the same if not higher quality (compared to the existing brands in the EU) directly to Europe, without third party intervention. This allows the price of the Apollo to be a lot lower than that of the machines, as we know them now in Europe.
Apollo is a well-known name in Asia. The manufacturer has been in business since 1967 and is one of the major players in the Asian market. Initially they produced Vertical Drilling machines, 15 years ago they also concentrated on Horizontal Drilling rigs.
The manufacturer boasts a long track record and many satisfied customers. The reliability of the machine is thus beyond question.
The Apollo is similar to the machines now used in the European market. Nevertheless, we spend time on commissioning the machine. Each machine comes with a comprehensive, clearly written manual in its own language. We also take the time to answer all questions about the machine. We do this on site, at the driller’s premises, in person. The German support comes directly from the manufacturer and is therefore well versed in the machine from the start and also knows how to communicate this clearly. In short, every machine comes with on-site training and is given to the people who will operate the machine.
We apply the usual guarantee of 1 year or 1,000 burning hours. This does not differ from alternative providers. What does set us apart is our level of support and service. If there are problems, we are there for you 24/7. Because we understand the (financial) consequences if a machine comes to a standstill. We know what is going on in the field and are ready to help you further. Our mobile service department is ready to come to you immediately to solve any problems. We work with our own mechanics who are both skilled in the field and communicate in English and German.
